T-Slot Table 2000x1200x200 Plasma nitrided with lengthways slots Leg standard equipment 650

T-Slot Table, with vertical / horizontal hole arrangement on the table top and parallel hole pattern in a 100 mm grid on the sides, as well as M10 threaded boreholes and lengthways slots. Due to the lengthways slots spaced 100 mm apart, components with an elongated hole can be horizontally mounted in any position. For this purpose threaded clamp bushings with t-nuts are required. We recommend using the T-Slot Table for "clean" or spatter-free welding tasks, since cleaning of the lengthways slots is very time consuming. Upon request, the T-Slot Table is available without boreholes. Extra charges for modifications: - distance between t-slots (standard 100 mm) - size of t-slots (standard 12 mm) - distance of threaded holes (standard 100 mm) - additional thread on upper surface - size of threaded holes (standard M10) Premium steel S355J2+N + Plasma nitration Leg Boot protects threaded arbor from dirt and prevents damages to the welding hose, due to the constant contact with the threaded arbor. Standard Leg, available in various lengths (special lengths upon request). Load-bearing capacity 2,000 kg, adjustable up to 50 mm (vernier adjustment). Our recommendation: Sleeve for Table Leg for every table leg with foot plate (Item No. 280859 for Leg standard equipment / Leg with Floor Anchoring System 28) (not included in the delivery) The specified load capacities refer to static load.

Product number: 280060.PNL
