Siegmund bench vice 100 with 16 mm boreholes

Siegmund bench vice 100 with 16 mm boreholes

SKU
€227,00 - €227,00
€227,00
€227,00 - €227,00
€227,00
The Siegmund bench vice is made of high-quality cast iron. The robust material and optimized design make the Siegmund bench vice a reliable and durable tool. The sliding carriage of the movable jaws is machined on 4 sides to ensure smooth sliding and precise clamping. The double bore holes allow the bench vice to be attached to the table at a 45° or 90° angle, according to your needs. The vice jaw covers are interchangeable and available in the materials fiber, rubber and aluminum. To attach the bench vice to the table, fast clamping bolts and if necessary, reduction bushings are required.

Product number: 004310

Standard shipping

Estimated delivery time: 7-10 days

Features:
- Clamping jaws, spindle and spindle key made of hardened quality steel
- opening to the front
- Jaw width 100 mm
- Opening stroke 100 mm
- Mounting Welding Table: System 16: 2x 160511, System 22: 2x 160513 + 2x 000541, System 28: 2x 160511 + 2x 000545
- Mounting Workbench: Steel plate: 2x Bolt 160514, Aluminum table profiles: 2x Bolt 160514, MDF protective plate with steel plate: 2x Bolts 160517, MDF protective plate with aluminum table profiles: 2x Bolt 160517
- When clamping in aluminium profiles, the Areal Clamping Bolt 160590 is recommended
- Delivery contents: 1x Bench vice 004310

Subgroup: Bench vice

Weight (kg): 9.5

Max Clamping Force (lbf): 20.0
