Square U-Shape 2000x100x100 Aluminum-Titanium

Square U-Shape 100x100, ideally suited as a table extension, for vertical setups, as well as a sturdy connection between two welding tables. The Square is firmly bolted to the table with Connecting Bolts (Item No. 160560.N). If the Square is used as a table extension exceeding 1,000 mm, it has to be supported by a table leg. A multitude of clamping- and combination options with other squares and stops are facilitated by the five-sided boreholes and the optional diagonal hole arrangement. Grid lines with a 50 mm spacing make orientation easier. From a length of 500 mm all U-shaped squares have mounting holes on the back to attach table legs. Aluminum-Titanium: We use this lightweight and high-strength material for weight reasons for some large stop and clamping squares. However, the hardness of nitrided cast steel can not be achieved here.

Product number: 160390.AT
