Square U-Shape 3000x400x200 Plasma nitrided

Square U-Shape 400x200 (sides 200 mm), is ideally suited as a table extension, for vertical setups, as well as a sturdy connection between two welding tables. Riser Blocks should only be joined to the table using connector bolts (Item No. 280560.N). When used as a table extension exceeding 1000 mm, the Riser Block has to be supported by a table leg. Combined with the legs (Item No. 280371), Riser Blocks can be flexibly used on the foundation rails. A multitude of clamping- and connection options, using different Riser Blocks and Stops, are facilitated by the five-sided boreholes and the optional diagonal hole arrangement. Grid lines with a 100 mm spacing make orientation easier. From a length of 500 mm all U-shaped squares have mounting holes on the back to attach table legs (except 280310.P).

Product number: 280392.2.P
