Siegmund Synchrolift SL 2500 (without U-Square) incl. rotatable ground connection

SKU
Original price €40.390,00 - Original price €40.390,00
Original price
€40.390,00
€40.390,00 - €40.390,00
Current price €40.390,00
TECHNICAL FEATURES ∙ Incl. control panel or manual control (wired), additional controls available for an extra charge ∙ Display for positioner setting ∙ Continuously adjustable rotation of the clamping plate ∙ Pallet lifter for repositioning Octagonal tables and U-squares are not included in delivery. The stable, rotatable ground connection directly on the device ensures an optimal connection to the tabletop even while rotating. The welding device is connected via a pin on the machine. Twisted ground cables are a thing of the past. Rotatable ground connector included.

Product number: 6S250M16

Standard shipping

Estimated delivery time: 7-10 days

Features:
- Table revolutions per minute (electric): 1
- Operating voltage 400 V 50 Hz
- Speed lifting and lowering: 56 cm/min
- Motor power turning: 0,75 kW
- Motor power lifting and lowering: 2 kW
- Tower height: 2505 mm
- Total stroke (B): 1500 mm
- movement range (C): 350-1850 mm
- Clamping plate diameter: Ø 600 mm

Subgroup: Synchrolift

Weight (kg): 1200.0

Load Capacity (kg): 2500
